Features
- Digital Class-D Mono Block Amplifier
- Dual MOS-FET PWM Power Supply
- 1 Ohm Stable Load
- 12 dB/Octave – Variable Low Pass Filter
- 0 to 12dB – Variable Bass Boost
- 4 Way Protection Circuit (Thermal Voltage Speaker short and DC Offset)
- Wired Remote Control with Clipping Indicator
Specifications
- Tested at 14.4 Volts
- 1Ohm Mono: 3500W RMS
- 2Ohm Mono: 3000W RMS
- 4Ohm Mono: 1750W RMS
- Recommended Fuse Rating: 300A
- Low Pass Filter: 40Hz – 20kHz
- High Pass Filter: 10Hz – 1kHz
- Level (Bass Boost): 0 – 12dB (50Hz)
- Input Sensitivity: 5V Max
- Single Noise Ratio: 108dB
- Working Voltage: 10.5V – 15.5V DC
- Dimensions (Inches): 8.86” x 7.28” x 2.44”
Remote bass knob included.
MINIMUM 0GA pure copper power wire for this amp!
